The 3000 Ton Flat Bottomed Steel silo

The 3000T flat bottomed steel silo is a heavy-duty storage equipment specially designed for static storage of oversized bulk materials, focusing on long-term closed storage of grain, feed raw materials, and industrial powders. The flat bottomed structure of the warehouse has a high utilization rate of storage capacity, balanced and stable load-bearing capacity, and is made of high zinc layer anti-corrosion board. It has excellent sealing and moisture-proof performance, convenient modular assembly, and is suitable for large-scale, long-term static storage scenarios such as grain depots and industrial parks. It has low operation and maintenance costs and strong durability.

Quantity:
Availability:





Inquire

The 3000 Ton Flat Bottomed Steel silo grain storage silo grain silo storage silo silo steel grain silo price grain storage steel silo steel storage silos prices for wheat food grade silo

Product Advantage

1. Ultra high warehouse capacity utilization rate (flat bottomed core advantage): By adopting a standardized flat bottomed structure, the utilization rate of warehouse capacity has increased by 15% -20% compared to cone bottom warehouses. The 3000T large capacity maximizes the utilization of site space and is suitable for long-term static storage of oversized materials, greatly improving the cost-effectiveness of warehousing.

2. Balanced load-bearing+heavy-duty stable structure: The bottom of the warehouse is reinforced with cement flooring and steel beams, ensuring even force distribution and no local deformation. The exterior of the warehouse is reinforced with thickened galvanized columns, and the structure remains stable under a full load of 3000T, suitable for heavy-duty storage of various bulk materials.

Technical Parameters

Serial Number	Item	Parameter Details
1	Warehouse height	Warehouse top angle of 25 °, cone bottom angle of 45 °
2	Core specifications of the warehouse body	Warehouse capacity 2231m ³, total height 27.27m, warehouse barrel height 16.87m
3	Material of fence and roof panel	1. Warehouse roof: 1.0mm thick cold base zinc aluminum magnesium SGC350 steel plate, with heat and corrosion resistance 5 times that of ordinary galvanized steel plate 2. Fence: High quality Handan Iron and Steel flower free oil-free double-sided galvanized BGH340/SGH440+275 corrugated board, with zinc aluminum magnesium content on both sides of 275g/㎡ 3. Thickness of cylinder plate: 2.5mm for the first layer, 1.5mm for the second to fifth layers, 2.0mm for the sixth to eleventh layers, 2.5mm for the twelfth to thirteenth layers, and 3.0mm for the fourteenth to fifteenth layers
4	Column configuration	39 external M-shaped galvanized columns with a width of approximately 312mm
5	Cone bottom and support accessories	The steel cone bottom is treated with overall painting, adopting a double ring beam and double column base design; Outer column base: 26 H294 × 200H steel welded into shape; Inner column base: 8 pieces of H194 × 150H steel welded into shape; Reinforcement material: Steel 75 * 7; Cone base plate thickness δ 8mm
6	Ancillary facilities	1 set of manhole for top maintenance and 1 set of silo shaft; 1 set of vertical climbing ladder inside the warehouse and 1 set of vertical climbing ladder outside the warehouse
7	Production, installation, and standards	On site installation, the corrugated plate of the silo is cold-rolled and produced by punching, bending, and shearing production lines with high precision; Bolt configuration: The warehouse roof and cylinder are equipped with 8.8 grade high-grade galvanized bolts (Shanghai Hardiwei/Jinyi), and key load-bearing parts are equipped with 10.9 grade high-strength galvanized bolts (Shanghai Hardiwei/Jinyi) components, matched with waterproof, wear-resistant, corrosion-resistant high-grade rubber gaskets (Fujian Yongda), and the bolts are wrapped with Shanghai Kejian aviation sealing strips; Sealing treatment: The joint of the enclosure board is sealed with Shanghai Kejian Aviation Sealing Cement, which is corrosion-resistant, highly viscous, and has excellent sealing performance (different from conventional bolts, gaskets, and rubber strips); Service life: 30 years

Product Uses

1. Large scale feed group reserve warehouse: As a strategic reserve warehouse for core raw materials such as soybean meal and corn for leading feed enterprises, the super large capacity reduces replenishment costs, and the high anti-corrosion board is resistant to raw material corrosion, suitable for long-term static storage, ensuring continuous supply of raw materials for production lines.

2. Large scale agricultural reclamation and planting bases: For the centralized storage of grain and economic crops in tens of thousands of acres of agricultural reclamation bases and planting consortia, flat bottomed warehouses have high land utilization and stable structure, which can realize the zoning storage of bulk materials, simplify the warehousing management process, and adapt to the centralized warehousing needs for autumn harvest.
