The 1500 Ton Conical Bottom Steel Silo

The 1500 ton conical bottom steel silo is a heavy-duty customized equipment designed for the storage of oversized bulk materials, specializing in the sealed and fresh-keeping storage of large quantities of grain, feed raw materials, and industrial granular powders. Adopting a 45 ° standard cone bottom design, material self discharge is achieved with zero residue and no blockage. The warehouse body is made of thickened high zinc layer anti-corrosion steel plate, which is tightly sealed, has strong load-bearing capacity, modular assembly is convenient, strong durability, and low operation and maintenance costs. It can meet the core needs of bulk storage, long-term reserve, and transit turnover of large grain depots, industrial parks, and collective bases.

Quantity:
Availability:





Inquire

The 1500 Ton Conical Bottom Steel silo grain storage silo grain silo storage silo silo steel grain silo price grain storage steel silo steel storage silos prices for wheat metal silo food grade silo

Product Advantage

1. Modular precision manufacturing and installation: Corrugated sheets are processed by automated cold rolling, punching, and bending production lines, with high dimensional accuracy and excellent splicing fit; Modular assembly of the entire machine on-site, compact footprint, short construction period, supports parallel expansion of multiple warehouses, and is suitable for large-scale site layout.

2. Special grade load-bearing+safety reinforcement design: External thickened and widened M-shaped galvanized columns are used to strengthen the overall load-bearing capacity, and key load-bearing parts are reinforced in multiple layers. The structure is stable under a full load of 1500 tons, and safety accessories such as warehouse doors and straight ladders are standard. Daily inspections and material control are safe and convenient.

Technical Parameters

Serial Number	Item	Parameter Details
1	Warehouse height	Warehouse top angle of 25 °, cone bottom angle of 45 °
2	Core specifications of the warehouse body	Warehouse capacity 2231m ³, total height 27.27m, warehouse barrel height 16.87m
3	Material of fence and roof panel	1. Warehouse roof: 1.0mm thick cold base zinc aluminum magnesium SGC350 steel plate, with heat and corrosion resistance 5 times that of ordinary galvanized steel plate 2. Fence: High quality Handan Iron and Steel flower free oil-free double-sided galvanized BGH340/SGH440+275 corrugated board, with zinc aluminum magnesium content on both sides of 275g/㎡ 3. Thickness of cylinder plate: 2.5mm for the first layer, 1.5mm for the second to fifth layers, 2.0mm for the sixth to eleventh layers, 2.5mm for the twelfth to thirteenth layers, and 3.0mm for the fourteenth to fifteenth layers
4	Column configuration	39 external M-shaped galvanized columns with a width of approximately 312mm
5	Cone bottom and support accessories	The steel cone bottom is treated with overall painting, adopting a double ring beam and double column base design; Outer column base: 26 H294 × 200H steel welded into shape; Inner column base: 8 pieces of H194 × 150H steel welded into shape; Reinforcement material: Steel 75 * 7; Cone base plate thickness δ 8mm
6	Ancillary facilities	1 set of manhole for top maintenance and 1 set of silo shaft; 1 set of vertical climbing ladder inside the warehouse and 1 set of vertical climbing ladder outside the warehouse
7	Production, installation, and standards	On site installation, the corrugated plate of the silo is cold-rolled and produced by punching, bending, and shearing production lines with high precision; Bolt configuration: 8.8 grade high-grade galvanized bolts (Shanghai Hardiwei/Jinyi) are used for the top and cylinder of the warehouse, and 10.9 grade high-strength galvanized bolts (Shanghai Hardiwei/Jinyi) are used for key load-bearing parts Billion) components, equipped with waterproof, wear-resistant, corrosion-resistant high-grade rubber gaskets (Fujian Yongda), bolts wrapped with Shanghai Kejian aviation sealing strips; Sealing treatment: The joint of the enclosure board is sealed with Shanghai Kejian Aviation Sealing Cement, which is corrosion-resistant, highly viscous, and has excellent sealing performance (different from conventional bolts, gaskets, and rubber strips); Service life: 30 years

Product Uses

1. Large scale land reclamation/modern planting base: for the large-scale land reclamation base, the bulk grain and cash crops of the ten thousand mu planting complex are uniformly distributed and stored, taking into account the grain agricultural means of production reserves, the structure is stable and durable, realizing the partition storage and centralized scheduling management of large quantities of materials, and improving the warehouse storage efficiency.

2. Grain and Oil Deep Processing Industrial Park Storage Cluster: Serving the centralized storage of raw materials for large-scale flour, oil, and rice processing industrial parks, multiple warehouses can be connected in parallel to form a storage group. The sealing system strictly controls the quality of raw materials, and the cone bottom has no residual discharge suitable for continuous processing, improving the overall material turnover efficiency of the park.
